Grid Parabolic Antenna

Grid Parabolic Antenna

 # Model Frequency Diameter Bandwidth Gain Download ENQ
1. AP-35016 330 - 400 MHz. 2.4 Meters 40 MHz. 16 dBi.
2. AP-35018 330 - 400 MHz. 3.0 Meters 40 MHz. 18 dBi.
3. AP-35020 330 - 400 MHz. 4.0 Meters 40 MHz. 20 dBi.
4. AP-45015 406 - 512 MHz. 1.8 Meters 40 MHz. 15 dBi.
5. AP-45018 406 - 512 MHz. 2.4 Meters 40 MHz. 18 dBi.
6. AP-45020 406 - 512 MHz. 3.0 Meters 40 MHz. 20 dBi.
7. AP-45022 406 - 512 MHz. 4.0 Meters 40 MHz. 22.5 dBi.
8. AP-145016 1300-1600 MHz 0.6 Meter 150 MHz. 16 dBi.
9. AP-145019 1300-1600 MHz 0.9 Meter 150 MHz. 19 dBi.
10. AP-145022 1300-1600 MHz 1.2 Meters 150 MHz. 22 dBi.
11. AP-145026 1300-1600 MHz 2.0 Meters 150 MHz. 26 dBi.
12. AP-145028 1300-1600 MHz 2.4 Meters 150 MHz. 28 dBi.
13. AP-145030 1300-1600 MHz 3.0 Meters 150 MHz. 30 dBi.
14. AP-145032 1300-1600 MHz 4.0 Meters 150 MHz. 32 dBi.
15. AP-180024 1700- 2000 MHz 1.2 Meters 150 MHz. 24 dBi.
16. AP-180032 1700- 2000 MHz 3.0 Meters 150 MHz. 32 dBi
17. AP-180027 1700-2000 MHz 1.8 Meter 150 MHz. 27 dBi.
18. AP-180030 1700-2000 MHz 2.4 Meters 150 MHz 30 dBi.
19. AP-180034 1700-2000 MHz 4.0 Meters 150 MHz. 34 dBi.
20. AP-240024 2300-2600 MHz 0.9 Meter 200 MHz. 24 dBi.
21. AP-240027 2300-2600 MHz 1.2 Meters 200 MHz. 27 dBi.
22. AP-240030 2300-2600 MHz 1.8 Meters 200 MHz. 30 dBi.
23. AP-240032 2300-2600 MHz 2.4 Meters 200 MHz. 32 dBi.
24. AP-240034 2300-2600 MHz 3.0 Meters 200 MHz. 34 dBi.
25. AP-240036 2300-2600 MHz 4.0 Meters 200 MHz. 36 dBi.
26. AP-2330-26 2305-2360 MHz 1.2 Meters 55 MHz 26 dBi
27. AP-2330-29 2305-2360 MHz 1.8 Meter 55 MHz 29 dBi.
28. AP-2330-32 2305-2360 MHz 2.4 Meters 55 MHz 32 dBi
29. AP-3530 3300-3800 MHz 1.2 Meters 500 MHz 30 dBi.
30. AP-85025 700 - 990 MHz. 3 Meters 80 MHz. 26 dBi.
31. AP-85017 700 - 990 MHz. 1.2 Meters 80 MHz. 17 dBi.
32. AP-85022 700 - 990 MHz. 2.0 Metres 80 MHz. 22 dBi.
33. AP-85028 700 - 990 MHz. 4 Meters 80 MHz. 28 dBi.

Antenna Experts manufacture grid parabolic antenna for 350 MHz, 450MHz, 700MHz, 800MHz, 900MHz, 1450MHz, 1800MHz, 1850MHz, 1900MHz, 2300MHz, 2450MHz and 3500MHz frequency bands.

Various size of grid parabolic antennas manufactured by us such as 0.6Meter (60 Cms), 0.9M (90 Cms), 1.2 Meters, 1.8 Meters, 2.4 Meters, 3 Meters and 4 Meters size with various gain starting from 15 dBi to 44 dBi depending on the frequency range. Grid parabolic antennas greater than 2.4 Meters supplied with 2 side struts for highest wind load / pressure and in two segments for easy of shipping and handling.

The AP series grid parabolic antenna are professionally made, economically priced antennas. The grid parabolic antenna design has the highest strength/weight ratio. These grid parabolic antenna are high efficiency antennas whose gain figures approach the theoretical maximum for the individual curved surface area.

The AP series grid parabolic antenna consists of full Parabolic reflector for use in point-to-point analogue and digital communication systems. The mounting arrangement of grid parabolic Antenna permits to change the polarization from horizontal to vertical and vice-versa.

The grid parabolic antenna operates at D.C. ground with low resistance discharge path for protection against lightning and immunity to noise. All the screws, nuts and bolts of grid parabolic antenna are of type 316 marine grade stainless steel.

The AP series grid parabolic antennas are supplied with Azimuth and Elevation tracking mechanism where the fine adjustments is necessary to optimized the signal strength of a radio link along with Two side struts to provide extra supports to the antenna.

Our 2300 MHz grid parabolic antenna AP-2330-26, AP-2330-29 & AP-2330-32 are 100% in compliance with FCC part 101.115 covering directional antenna especially the front to back ratio, beam-width and cross polarization discrimination for WCS and BRS/EBS band.

Our grid parabolic antenna AP-180024, AP-180027, AP-180030, AP-180032 are highly suitable for Studio-To-Transmitter STL link for broadcast application. The VSWR of these STL link grid parabolic antenna is very low i.e. better than 1.15:1.
