The HFM-230 Multi Wire Broad Band Folded Dipole Antenna manucatured by Antenna Experts offer optimum performance, fully automatic, low SWR operation over the entire HF band 1.5–30 MHz and suitable for transmitting, receiving or HF spectrum monitoring or surveillance. The efficiency of HFM-230 HF multi-wire broadband dipole antenna is much higher as compare to HF broadband folded dipole antenna.


The HFM-230 HF 3 wire broadband dipole antenna propagates NVIS, local, medium or long distance communications. This HF broadband dipole antenna is ready to go right out of the box, no taps to change frequency, nothing to tune - ever! Designed for the military and built to last. The HFM-230 can work any frequency you want without going through a lot of knob twirling and measurements to get a good VSWR match - just set your frequency and go!


The HFM-230 HF 3-wire or multi wires broadband antenna is designed for broad band operation for fixed stations application. The radiating element of dipole is made of ultra corrosion resistant marine grade stainless steel to ensure the survivability in worst environment conditions.


The HFM-230 HF 3-Wire or multi wire broadband dipole antenna can be mounted either in an inverted “V” using a single mast, or in a standard dipole configuration (Horizontal Polarized) using two masts. The HF Broad Band Dipole Antenna provides optimum performance over complete HF band, eliminating the requirement of multiple antennas or an Antenna Tuning Unit, minimizing the cost and setup requirements.


The HFM-230 HF multi wire broad band dipole antenna comes with 28 meters standard length and 30 meters horizontal spacing/distance is recommended between 2 mast where as The HFM-230-56 HF multi wire broad band dipole antenna comes with 56 meters extended length and 58-60 meters horizontal spacing/distance is recommended between 2 mast. Extended length of HFM-230-56 HF multi wire antenna ensure higher efficiency especially at lower frequency.



Please visit our "HF Broadband Dipole Antenna" section of our website for more details on ultra HF multi wire broadband antennas products datasheets and installation manual in pdf format. You can also request more information about HF 3 wires broadband dipole antenna like VSWR curve and radition patterns.
