RCIED Jammer Antenna

RCIED Jammer Antenna
 # Model Frequency Bandwidth Gain Download ENQ
1. JC-134-174 134 - 174 MHz. 40 MHz. 0 dBi.
2. JD-525 500 - 2500 MHz. Entire Band 2.5 dBi.
3. JD-500-800 500 - 800 MHz. Entire Band 2.5 dBi.
4. JC3-900 800 - 1000 MHz. Entire Band 2.5 dBi.
5. JC8-850 820 - 960 MHz. Entire Band 8 dBi.
6. JD-1018 1000 - 1800 MHz. Entire Band 2.5 dBi.
7. JCM-1030 1000-3000MHz 1 - 3 GHz 2 dBi.
8. JCD-1000-6000 1000-6000 MHz 1-6 GHz 2 dBi
9. JCD-100-1300 100-1300 MHz 100-1300 MHz 2 dBi.
10. CM-100-500 100-500 MHz 100-500MHz 2.15 dBi
11. JC-108-174 108 - 174 MHz 108-174 MHz -2 dBi
12. QHA-1113 1100-1300 MHz 1.1 - 1.3GHz 2 dBic
13. QHA-1117 1100-1700 MHz 1100-1700MHz 2 dBic
14. JCD-1216 1200-1600 MHz Entire Band 2.5 dBi
15. JC5-1216 1200-1600 MHz Entire Band 5 dBi
16. JCM7-1227 1210 - 1240 MHz 40 MHz 7 dBi.
17. JC7-1227 1210 - 1240 MHz 40 MHz 7dBi.
18. HR-1227-5 1210-1240 MHz 1210-1240MHz 5 dBi
19. QHA-1417 1400-1700 MHz 1.4 - 1.7GHz 2 dBic
20. QHA-1516 1500-1620MHz 1.50 - 1.62 MHz 2 dBic
21. JC10-1600 1500-1700 MHz 1500-1600MHz 10 dBi
22. JCM7-1575 1550 - 1590 MHz 40 MHz 7 dBi.
23. JC7-1575 1550 -1590 MHz 40 MHz 7 dBi.
24. HR-1575-5 1550-1590 MHz 1550-1590MHz 5 dBi
25. JC10-1850 1800 - 1880 MHz. 1800-1880MHz 10 dBi
26. JC3-1820 1800 - 2000 MHz. Entire Band 3 dBi.
27. JCM9-1850 1800-1870 MHz 1800 - 1870MHz 9 dBi
28. JC10-1900 1800-1990 MHz 1800-1900MHz 10 dBi
29. JC3-2025 2000 - 2500 MHz. Entire Band 3 dBi.
30. JCS10-2100 2000-2170 MHz 2 - 2.17 GHz 10 dBi
31. JC10-2100 2000-2170 MHz 2000-2170MHz 10 dBi.
32. JC4-2025 2000-2500 MHz 2-2.5GHz 4 dBi
33. JCS4-2025 2000-2500 MHz 2 - 2.5 GHz 4 dBi
34. JC10-2250 2000-2500 MHz. 2 - 2.5 GHz. 10 dBi.
35. JCS-20-100 20-100 MHz 20 - 100 MHz -6-0 dBi
36. LP-20-3000L 20-3000 MHz 20-3000MHz 6 dBi
37. JCM-20-520 20-520 MHz 20 - 520 MHz Typ 0 dBi
38. JC12-2130 2110 - 2170 MHz. Entire Band 12 dBi.
39. JCM9-2150 2110-2170 MHz 2110 - 2170MHz 9 dBi
40. JC12-2450 2400 - 2500 MHz. Entire Band 12 dBi.
41. JC10-2450 2400-2500 MHz. 2.4 - 2.5GHz. 10 dBi.
42. JC12-2550 2400-2700 MHz 2400-2700MHz 10 dBi
43. JC3-2530 2500 - 3000 MHz. Entire Band 3 dBi.
44. JCD-2500-6000 2500-6000 MHz 2500-6000MHz 2 dBi
45. JC-25-66 25-66 MHz Entire Band -5 dBi
46. JCS10-2650 2600-2700 MHz 100 MHz 10 dBi.
47. JC-30-88 30 - 80 MHz Entire Band -2 dB.
48. JCD-300-3000 300-3000 MHz 300 - 3000MHz 2 to 0 dBi
49. CD5-300-400 300-400 MHz 300-400MHz 5 dBi
50. CD5-400-470 400-470 MHz 400-470MHz 5 dBi
51. AC-430-470 430-470 MHz Entire Band 3 dBi
52. CD5-470-530 470-530 MHz 470-530MHz 5 dBi
53. JCD-500-2500 500-2500 MHz 500-2500MHz 2 dBi
54. JWD-500-3000 500-3000 MHz 500-3000MHz 2.15 dBi
55. JC12-5250 5100-5400 MHz 5100-5400MHz 12 dBi
56. JC-66-88 66-88 MHz Entire Band 0 dBi
57. JCD-700-2500 700-2500 MHz. 700-2500MHz 2 dBi.
58. JC5-900 800-1000 Mhz 200 MHz. 5 dBi
59. JCD-0820 800-2000 MHz Entire Band 2 dBi
60. GPHP-800-2000 800-2000 MHz 800-2000 MHz 2 dBi.
61. WDHP-800-2000 800-2000 MHz 800-2000 MHz 2 dBi.
62. LPHP-800-2000 800-2000 MHz 800-2000 MHz 9 dBi
63. JC10-900 850-960 MHz 850-960MHz 10 dBi
64. JCM7-950 925-960 MHz 925 - 960MHz 7 dBi

RCIED Jammer Antenna manufactured by Antenna Experts offers true omni directional radiation pattern and wide vertical / elevation beamwidth providing excellent null fill for consistent signal coverage. Many of our RCIED jammer antennas are ground independent antenna which does not require any ground plane for its operation. The RCIED jammer antenna features high suppression of skin current which provides the constant and superior performance over the specified frequency band.

Antenna Experts manufactured very high power handling jammer antenna for omnidirectional coverage and directional coverage. Our LPHP-800-2000 log periodic directional antenna is capable of handling 400 Watts CW power and our WDHP-800-2000 omnidirectional discone antenna is capable of handling 500 watts CW power. Similarly our GPHP-800-2000 omnidirectional ground plane antenna is capable of handling 500 watts CW power. All these three antennas are ground independent. No ground plane is required to operate these antennas. All these high power jammer antenna are sealed in a radome/housing to make these 100% weather proof. LPHP-800-2000, WDHP-800-2000 and GPHP-800-2000 high power handling jammer antenna cover the entire 800-2000MHz frequency band with single antenna.

RCIED wideband vehicular mount antennas manufactured by Antenna Experts for HF, VHF, UHF and Microwave bands are a crucial element of today’s demanding RF systems that are used in tactical communication, electronic countermeasure and spectrum monitoring applications. RCIED vehicular jammer antennas are ruggedized to withstand tough MIL standard of MIL-STD-810F environmental specifications making these jammer antenna an ideal choice for installations on all kind of vehicles as well as for fixed installations like on masts, shelters or containers.

Antenna Experts provide RCIED jammer antenna with high power levels from 100 – 500 W that don’t require any additional adjustments. Our highly reliable wideband antennas feature NATO 4/6 holes/ US pattern and compatible mountings fitted with stainless steel spring, making them perfect for the latest RF systems used in i.e. C3I, EW, EOD, VIP and convoy protection applications.

RCIED Jammers Antennas are highly suitable for Electronic Counter Measure (ECM) against Radio Controlled Improvised Explosive Device (RCIED), Convoy Protection, Prisons Jamming, Large Campuses Jamming, Conference Room Jamming , VIP Protection, Cellular Jamming and Digital Bomb Jamming applications. Antenna Experts manufactures wide range of Jammer Antennas for Radio-Controlled Improvised Explosive Device application covering the HF VHF and UHF frequency bands including GSM, EGSM, CDMA, WCDMA, AMPS, TDMA, UMTS, 3G, 4G, LTE, WLAN, ISM, GPS, Wi-Fi, Satellete and Bluetooth bands.

JC and CD series RCIED Jammer Collinear Antennas are wide band, light weight and high gain antennas, where as JD series RCIED Jammer Discone Antennas are ultra wideband, heavy duty and unity gain antennas. Both jammer collinear antennas and jammer ultra wideband discone antennas are suitable for mount on the vehicle as well as on the mast/tower. Antenna Experts also manufactures broadband coaxial dipole antenna for RCIED jamming application with cylindrical radome. Jammer Antenna can be supplied with customized mounting brackets for variety of application like fixed station, vehicular mounting and manpack applications.

The LP-20-3000L tactical log periodic jamming antenna is designed to provide wideband directional jamming signals from 20-3000 MHz bands due to its broad band design feature, small size and high power handling capacity, making it highly suitable for mobile and tactical applications. The tactical LP antenna can be assembled in less than 10 minutes. The shipping length of high power jammer antenna is 6 feet. The LP-20-3000L assembled tactical log periodic antennas outer-most dimensions are 3 meters (10 feet) long and 3 meters (10 feet) wide.

QHA Series broadband omni-directional RHCP quadrifilar helix antennas are rugged all weather model, enclosed in a ABS radome, uses high class copper alloy and does not require any field tuning or adjustments. The compact size of RHCP omni-directional quadrifilar helix antenna allows easy handling, shipping and highly suitable for receiving, transmitting, scanning, monitoring, surveillance and jamming applications for L band including GPS L1 and GPS L2 bands without having the requirement of multiple antennas. Antenna termination fitted just below the NATO mounting flange for complete weather protection. Other type of mounting hardware / configuration can be supplied on request. The RHCP quadrifilar helix antenna is consisting of two (pair) vertical loop radiating elements at right angles to each other, twisted into a helix turns vertically and enclosed in ABS radome. The special “Teflon Dielectric Transmission Line” technique is used to handle high power handling capacity allowing smooth VSWR and typical 2dBi. gain over the specified frequency band.

The CM-100-500 conical monopole antenna is designed to propagate line of sight communications and is characterized by stable radiation pattern with their long term reliability and stability of electrical characteristics. CM-100-500 is an excellent choice for omnidirectional VHF communications for RCIED jamming application for vehicular platform. Due to its large diameter to height ratio the VHF vertical conical monopole has excellent VSWR and omni-directional radiation pattern performance over 100-500MHz frequency range. VHF broadband vertical conical monopole antenna provides optimum performance over 100-500MHz band, eliminating the requirement of multiple antennas or an ATU, minimizing the cost and setup requirements. The antenna is supplied with removable radiating elements for easy of shipping and handling which can be assembled in the field with simple hand tools.

Antenna Experts produces a full range of vehicle-installed jammer antennas, for Force Protection for military, security forces, convoy protection, VVIPs protection and other government organizations. Antenna Experts have a number of antenna solutions to fit the customers requirements, ranging from a low profile roof box to a bespoke designed ground plane for optimum system performance. Our broad set of vehicle antennas is complemented by a wide selection of accessories including special mounting solutions and NATO antenna adaptor base plates to mount the antenna on vehicular. Our JCS series jammer Omni antennas supplied with stainless steel bi-conical spring fitted at the base of NATO flange.

Our JCM series antenna are specially designed for manpack application. These antenna can also be supplied with spring at base for more flexibility. Our JCM-20-520 antenna is deigned for 20-520MHz manpack jammer application for VHF and UHF bands. Our JCM7-950 manpack jammer antenna is designed for GSM 925-960MHz band with 7 dBi gain. Our JCM9-1850 manpack jammer antenna is designed for GSM 1800-1870MHz band with 9 dBi gain. Our JCM9-2150 manpack jammer antenna is designed for UMTS 2110-2170 MHz band with 9 dBi gain. Our JCM-1030 manpack jammer antenna is designed for GSM, CDMA, GPS, UMTS, ISM band covering entire 1000 - 3000 MHz frequency with 2 dBi gain.

The JCM7-1227 and JCM7-1575 Jammer manpack collinear antennas are rugged all weather model, enclosed in a ABS radome, uses high quality brass radiating elements and does not require any field tuning or adjustments. The compact size of omni-directional antenna allows easy handling, shipping and highly suitable for transmitting, receiving including GPS L2 GPS L1 band without having the requirement of multiple antennas. Cylindrical enclosure is used for low wind loading and for minimal effect of ice formation on the antenna operation as well as providing an aesthetically pleasing appearance. These high gain jammer manpack antenna have smooth VSWR and constant Gain over the respective GPS frequency band. The JCM series jammer antenna consists of ultra corrosion resistant radiating elements and enclosed in ABS housing. The ABS has excellent transparency for Radio Signal and mechanically Robust to support extra mechanical strength to the antenna.

The HR-1575-5 and HR-1227-5 horn antennas uses 6063T6 ultra corrosion resistant architectural anodized aluminum alloy and designed to provide wideband directional transmission/reception of radio signals from 1550-1590 MHz bands including GPS L1 bands and 1210-1240MHz band including GPS L2 bands respectively. These low-profile horn antenna uses Linear Polarization Antenna Technology - which can be changed in the field from Vertical to Horizontal and vice versa. This commercial grade horn antenna provides medium performance while maintaining the wider beam-width as compare to significantly larger and more expensive products. The specially designed mounting arrangement results in fast installation. The horn antenna is supplied complete in assembled condition. This horn antenna system is particular suitable for transmission, reception, monitoring, scanning and jamming applications due to its broad band design feature.

The HR series horn antennas are supplied with powder coating finish to protect the antenna further from severe environmental condition. This horn antenna can be supplied with dual linear polarization to receive both V & H polarization signals simultaneously for polarization diversity (Optional). The HR Series Horn Antennas are light weight, broadband and rugged horn antenna, ready mobility, easily mounts, supplied with fiberglass radome to protect the antenna from environment. N-Female output termination of horn antenna is fixed directly at the wall of horn antenna. All the screws, nuts and bolts of horn antenna are made of marine grade stainless steel.

Antenna Experts would be pleased to discuss your specific requirements in more details.
